PC200-8 Bucket Cylinder Hydraulic Excavator Cylinder 707-01-0H740 707-01-0J270 For Komatsu

1
MOQ
Negotiation
Price
PC200-8 Bucket Cylinder Hydraulic Excavator Cylinder 707-01-0H740 707-01-0J270 For Komatsu
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Hydraulic Bucket Cylinder
Product Alias: Excavator Hydraulic Cylinder
Models: PC200-8
Other Models: HB215 PC200 PC200LL PC210 PC228 PC228US
PN1: 22T-75-13511 20R-63-66441 22J-63-96241 421-43-38730
PN2: 209-63-X6470 721-11-11990 21W-63-99041 21U-63-76540
PN3: 707-01-OR830 21A-63-76140 707-00-0H521
Surface Treatment: Piston Rod Hard Chromium Plating Cylinder Tube ,Inner Honed
Seal Brand: For Japan NOK And US SKF
Seal Material: PU
Testing: 100% Pressure Testing Before Delivery
Factory Direct Supply: Yes
Basic Infomation
Place of Origin: Made In China
Brand Name: Glparts
Certification: ISO9001
Model Number: PC200-8
Payment & Shipping Terms
Packaging Details: Wooden Case
Delivery Time: 7 Days
Payment Terms: T/T,Western Union,MoneyGram
Supply Ability: 2000pieces/month
Product Description

PC200-8 Bucket Cylinder Hydraulic Excavator Cylinder707-01-0H740 707-01-0J270 For Komatsu



Product Description



Product Name

PC200-8 Hydraulic Bucket Cylinder

Model

PC200-8

Part Number

707-01-0H740 707-01-0J270

Compatible other Models For Komatsu

HB215 PC200 PC200LL PC210 PC228 PC228US

Other Part Number We Provided

22T-75-13511 20R-63-66441 22J-63-96241 421-43-38730 209-63-X6470 721-11-11990 21U-63-76540

Temperature Range

-20-80°C

Pressure Range 21 MPa to 35 MPa
Dimensions Customized

OEM

Yes


Service Stage Details
PreSales Service Free consultation and technical advice
Customization options for dimensions and performance based on customer requirements
InSales Service Fast production and delivery times
Real-time updates on manufacturing and shipment status
AfterSales Service Warranty on manufacturing defects
Technical support for installation and maintenance

ps.If you are looking for other hydraulic cylinders for the PC200-8,please contact us for a quote


List Of Spare parts



707-01-0H740
Pos Part No Qty Parts name Comments

707-01-0H740 [1] Cylinder Assembly For Komatsu 149 kg.
1 707-13-11740 [1] Cylinder For Komatsu 0.000 kg.
2 707-58-80870 [1] Rod, Piston For Komatsu 82 kg.
3 707-76-70651 [1] Bushing For Komatsu 1.11 kg.
4 07145-00070 [2] Seal, Dust, (Kit : K13) For Komatsu China 0.034 kg.
5 07020-00000 [1] Fitting, Grease For Komatsu China 0.006 kg.
6 707-76-70120 [1] Bushing For Komatsu China 1.08 kg.
7 20Y-70-23220 [2] Seal, Dust, (Kit : K13) For Komatsu China 0.05 kg.
9 707-27-11870 [1] Head, Cylinder For Komatsu 6.3 kg.
10 707-56-80740 [1] Seal, Dust, (Kit : K13) For Komatsu 0.000 kg.
11 07179-13094 [1] Ring, Snap For Komatsu 0.02 kg.
12 707-51-80030 [1] Packing, Rod, (Kit : K13) For Komatsu China 0.04 kg.
13 707-51-80650 [1] Ring, Buffer, (Kit : K13) For Komatsu 0.01 kg.
14 707-52-90561 [1] Bushing For Komatsu 0.15 kg.
15 707-35-91150 [1] Ring, Back-up, (Kit : K13) For Komatsu China
16 07000-15105 [1] O-ring, (Kit : K13) For Komatsu China 0.01 kg.
17 01010-81670 [12] Bolt For Komatsu 0.142 kg.
18 01643-51645 [12] Washer For Komatsu 0.021 kg.
19 707-75-80040 [1] Ring, Snap For Komatsu 0.02 kg.
20 707-36-11880 [1] Piston For Komatsu China
21 707-44-11250 [1] Ring, Piston, (Kit : K13) For Komatsu 0.472 kg.
22 707-39-11530 [2] Ring, Wear, (Kit : K13) For Komatsu 0.025 kg.
23 707-44-11920 [2] Ring For Komatsu 0.051 kg.
24 01310-01216 [1] Screw For Komatsu 0.02 kg.
25 07000-15070 [1] O-ring, (Kit : K13) For Komatsu China 0.029 kg.
26 707-35-90360 [2] Ring, Back-up, (Kit : K13) For Komatsu 0.05 kg.
27 707-86-67750 [1] Tube For Komatsu 3.802 kg.
28 707-88-22570 [2] Bracket For Komatsu China
29 07372-21060 [2] Bolt For Komatsu 0.045 kg.
30 01643-51032 [2] Washer For Komatsu 0.17 kg.
31 07372-21045 [2] Bolt For Komatsu 0.039 kg.
33 07000-13030 [1] O-ring, (Kit : K13) For Komatsu 0.001 kg.
34 707-88-21271 [2] Band For Komatsu China
35 07372-21035 [4] Bolt For Komatsu 0.033 kg.
37 07283-32738 [2] Clip, Pipe For Komatsu 0.084 kg.
38 01597-01009 [4] Nut For Komatsu 0.011 kg.
39 01643-31032 [4] Washer For Komatsu 0.054 kg.

PC200-8 Bucket Cylinder Hydraulic Excavator Cylinder 707-01-0H740 707-01-0J270 For Komatsu 0

707-01-0J270
Pos Part No Qty Parts name Comments
G-1 707-01-XR270 [1] CYLINDER GROUP,(FINAL COATING) For Komatsu China
1 707-01-0J270 [1] CYLINDER ASSY For Komatsu China
1 707-13-11740 [1] CYLINDER For Komatsu 0.000 kg.
2 707-76-70651 [1] BUSHING For Komatsu 1.11 kg.
3 07145-00070 [2] SEAL,DUST (KIT) For Komatsu China 0.034 kg.
4 707-58-80870 [1] ROD,PISTON For Komatsu 82 kg.
5 707-76-70120 [1] BUSHING For Komatsu China 1.08 kg.
6 20Y-70-23220 [2] SEAL,DUST (KIT) For Komatsu China 0.05 kg.
7 707-27-11870 [1] HEAD,CYLINDER For Komatsu 6.3 kg.
8 07179-13094 [1] RING,SNAP For Komatsu 0.02 kg.
9 195-63-92190 [1] SEAL,DUST (KIT) For Komatsu 0.04 kg.
10 707-52-90560 [1] BUSHING For Komatsu 0.15 kg.
11 707-75-80040 [1] RING,SNAP For Komatsu 0.02 kg.
12 707-51-80030 [1] PACKING,ROD (KIT) For Komatsu China 0.04 kg.
13 07000-15105 [1] O-RING (KIT) For Komatsu China 0.01 kg.
14 707-35-91150 [1] RING,BACK-UP (KIT) For Komatsu China
15 707-51-80650 [1] RING,BUFFER (KIT) For Komatsu 0.01 kg.
16 01010-81670 [12] BOLT For Komatsu 0.142 kg.
17 01643-51645 [12] WASHER For Komatsu 0.021 kg.
18 707-36-11880 [1] PISTON For Komatsu China
19 707-44-11250 [1] RING,PISTON (KIT) For Komatsu 0.472 kg.
20 707-39-11530 [2] RING,WEAR (KIT) For Komatsu 0.025 kg.
21 707-44-11920 [2] RING For Komatsu 0.051 kg.
22 707-35-90360 [2] RING (KIT) For Komatsu 0.05 kg.
23 07000-15070 [1] O-RING (KIT) For Komatsu China 0.029 kg.
24 01310-01216 [1] SCREW For Komatsu 0.02 kg.
25 07020-00000 [1] FITTING,GREASE For Komatsu China 0.006 kg.
27 707-86-67750 [1] TUBE For Komatsu 3.802 kg.
28 07372-21060 [2] BOLT For Komatsu 0.045 kg.
29 01643-51032 [2] WASHER For Komatsu 0.17 kg.
30 07372-21045 [2] BOLT For Komatsu 0.039 kg.
32 07000-13030 [1] O-RING (KIT) For Komatsu 0.001 kg.
33 707-88-22570 [2] BRACKET For Komatsu China
34 707-88-21271 [2] BAND For Komatsu China
35 07372-21035 [4] BOLT For Komatsu 0.033 kg.
37 07283-32738 [2] CLIP For Komatsu 0.084 kg.
38 01597-01009 [4] NUT For Komatsu 0.011 kg.
39 01643-31032 [4] WASHER For Komatsu 0.054 kg.
40 707-88-33030 [2] CAP For Komatsu 0.011 kg.
41 07371-30640 [4] FLANGE,SPLIT For Komatsu China 0.112 kg.
KIT 707-98-39610 [1] SERVICE KIT For Komatsu China 0.342 kg.

PC200-8 Bucket Cylinder Hydraulic Excavator Cylinder 707-01-0H740 707-01-0J270 For Komatsu 1

Company Information




GuangZhou GuoLi Engineering Machinery Co., Ltd., with over 16 years of experience in excavator hydraulic cylinders, is a foreign trade company specializing in a wide range of products, including crawler excavator arm cylinders, boom cylinders, bucket cylinders, cylinder tubes, cylinder rods, custom hydraulic cylinders, seal kits, hydraulic pumps, and electric parts, all designed for various excavator models. Our products have been exported to over 100 countries and regions worldwide.


Factory Tour



Our main product, excavator cylinders, is produced through a complete hydraulic cylinder production line, from design to manufacturing. With over ten years of experience, we’ve upgraded our offerings to multi-stage hydraulic cylinders. We focus on cylinder customization and produce a variety of domestic and imported excavator cylinders. Using advanced CNC lathes, grinders, and assembly equipment, we strictly follow ISO quality standards throughout production.


Piston Rod Production Process




Feature Description
Material Tempered steel
Surface Treatment Induction hardened before chrome plating to prevent bending and scratching
Rust Resistance Resists rust for over 100 hours in salt spray tests
Production Process Produced and electroplated in-house
Finish Mirror finish technology


PC200-8 Bucket Cylinder Hydraulic Excavator Cylinder 707-01-0H740 707-01-0J270 For Komatsu 3

Automatic Welding Process




Feature Description
Welding Method Fully automated welding for consistency and integrity
Craftsmanship Lean welding craft ensures strong joint strength and eliminates defects
Weld Seam Quality Weld seam matches the appearance of original parts
Durability Welded parts are not easy to fall off


PC200-8 Bucket Cylinder Hydraulic Excavator Cylinder 707-01-0H740 707-01-0J270 For Komatsu 4

Finished Product Warehouse Display


PC200-8 Bucket Cylinder Hydraulic Excavator Cylinder 707-01-0H740 707-01-0J270 For Komatsu 5




Exhibition Showcase



Our Presence at Major Exhibitions: 2023 Malaysia & 2024 Shanghai Bauma



Exhibition With Cooperated Clients




Certificates





Certification


FAQ





1.How can I be sure the part will fit my excavator ?

  • Give us correct model number /machine serial number /any numbers on the parts itself.

  • Or measure the parts give us dimension or drawing.


2.What material do you use on hydraulic cylinder?

  • High frequency quenching No.40 manganese steel as rod material so the cylinder rod has better bending resistance.

  • No.25 manganese steel as tube material ,so the tube has better wear resistance,

    High-strength hardened steel as rod head and tube head ,so the cylinder head and rod head more durable.

  • Name-brand seal kits to reduce the hydraulic cylinder oil leakage rate.


3.How long can an order delivery?

  • For some often used models of excavator hydraulic cylinder , we have in stock, within 7 days .

  • For any order less than one container takes about 2 weeks to finish; Order of 1-2 container takes 4 -6weeks.

  • At busy manufacturing season, manufacturing time needs more which can confirm by discussion.


4.How to pay?

  • Order less than 3000USD, full payment at order, Order over USD3000 value ,50% deposited in to start,

    50% balance paid to deliver,inspection service accepted.

  • For customized order, 70%payment as deposit ,30% balance paid to deliver.


5.How to delivery?

  • If you have shipping agent ,we will cooperate with your agent to arrange shipment .

  • If not , we have good relationships with shipping companies, express suppliers.

  • For light goods ,by UPS/DHL/TNT(DAP terms) , For heavy goods ,by sea (FOB,CIF,CFR)
