SK200 SK200LC Boom Arm Bucket Cylinder 2438U1109F1 2438U1103F1 Excavator Cylinder For Kobelco

1
MOQ
Negotiation
Price
SK200 SK200LC Boom Arm Bucket Cylinder 2438U1109F1  2438U1103F1 Excavator Cylinder For Kobelco
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Bucket Arm Boom Cylinder For Kobelco
Product Alias: Excavator Hydraulic Cylinder
Part Number: 2438U1109F1 2438U1103F1 2438U1109F2
Suitable For Other Models: SK200LC SK200 MD200C SK300LC-2 SK220LC SK220 SK300-2 SK300 SK210 CLAMSHELL SK210LC
Other Excavator Cylinder Parts: 2438U1108 2438U1107 2438U1106 2438U1105 2438U1128 2438U1129 2438U1130 2438U719
Surface Treatment: Piston Rod Hard Chromium Plating Cylinder Tube ,Inner Honed
Seal Brand: For Japan NOK And US SKF
Seal Material: PU
Testing: 100% Pressure Testing Before Delivery
Factory Direct Supply: Yes
Basic Infomation
Place of Origin: Made In China
Brand Name: Glparts
Certification: ISO9001
Model Number: SK200 SK200LC
Payment & Shipping Terms
Packaging Details: Wooden Case
Delivery Time: 7 Days
Payment Terms: T/T,Western Union,MoneyGram
Supply Ability: 2000pieces/month
Product Description

SK200 SK200LC Boom Arm Bucket Cylinder 2438U1109F1  2438U1103F1 Excavator Cylinder For Kobelco



Product Description




Product Name

Hydarulic Boom Bucket Stick Cylinder

Model

SK200 SK200LC

Compatible With Other Kobelco ModelsSK200LC SK200 MD200C SK300LC-2 SK220LC SK220 SK300-2 SK300 SK210 CLAMSHELL SK210LC
Part Number Of SK140 Hydraulic Cylinder Bucket Cylinder

2438U1109F1  2438U1103F1 2438U1109F2

Temperature Range

-20-80°C

Pressure Range21 MPa to 35 MPa
DimensionsCustomized

OEM

Yes



Service StageDetails
PreSales ServiceFree consultation and technical advice
Customization options for dimensions and performance based on customer requirements
InSales ServiceFast production and delivery times
Real-time updates on manufacturing and shipment status
AfterSales ServiceWarranty on manufacturing defects
Technical support for installation and maintenance

ps.If you are looking for other hydraulic cylinders for the SK200, please contact us for a quote


List Of Spare Parts



PosPart NoQtyParts nameComments

2438U1109F1[1]CYLINDERKOB ASSY (BUCKET), Remarks: CONSISTS OF THE FOLLOWING PARTS
12438U1109S1[1]BARRELKOB TUBE, CYLINDER
22438U1106S2[2]BUSHINGKOB ID 79.29mm x OD 90.12mm x H 89.98mm
3R45P0049D2[1]SEALKOB
42438U1109S4[1]PISTON RODKOB ROD, PISTON
52438U1109S5[1]PISTONKOB
6ZD12G08000[1]O-RING,79.40mm ID x 85.60mm OD x 3.10mmKOB ID 79.40 ± 0.69 x OD 85mm
7ZD75G08000[2]BACK-UP RINGKOB RING, BACK UP
8R45P0051D4[1]O-RINGKOB
92438U1109S9[2]WEAR RINGKOB RING, WEAR
102438U995S10[2]WEAR RINGKOB RING, WEAR
112438U995S11[1]NUTKOB PISTON
122438U308S45[1]LOCKING RINGKOB RING, LOCK
132438U1109S13[1]COVERKOB ROD
142438U1109S14[1]BUSHINGKOB
152438U718S22[1]CLIPKOB
16ZD12G11500[1]O-RING,114.40mm ID x 120.60mm OD x 3.10mmKOB ID 114.40 ± 0.94 x OD 120mm
17ZD75G11500[1]BACK-UP RINGKOB RING, BACK UP
182438U1106S21[1]RINGKOB
19R45P0050D9[1]RUBBER SEALKOB SEAL, STEP
2045Z91D44[1]O-RINGKOB
212418U130D34[1]PACKINGKOB SEAL Superseded by part number: Y0496604500
222438U928S33[1]SEALKOB DUST
23ZS23C14055[12]SCREW,Hex Socket Head, M14 x 55mmKOB M14x2.0x55mm
242438U995S24[1]U-BRACKETKOB BRACKET
252438U915S22[1]BANDKOB BRACKET
26ZS16C10030[2]CAPSCREWKOB M10x1.50x30mm Superseded by part number: ZS18C10030
27ZW26X10000[2]LOCK WASHERKOB ID 10 x OD 18 x Th 2.5mm
282438U1109S28[4]SEALKOB DUST

2438U1109R100[1]REPAIR KITKOB Remarks: CONSISTS OF ITEM 3, 6~10 Superseded by part number: 2438U1109R100P

2438U1109R200[1]REPAIR KITKOB Remarks: CONSISTS OF ITEM 16~22 Superseded by part number: 2438U1109R200P

2438U1109R300[1]REPAIR KITKOB Remarks: CONSISTS OF ITEM 3, 6~10, 16~22 Superseded by part number: 2438U1109R300P
