9260971 9169646 Slewing Bearing for ZX200-3 ZAX240-3 ZX200-5G Excavator Swing Ring Circle

1
MOQ
Negotiation
Price
9260971 9169646 Slewing Bearing for ZX200-3 ZAX240-3 ZX200-5G Excavator Swing Ring Circle
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Excavator Slewing Bearing For Hitachi ZX200-3 ZAX240-3 Excavator
Number: 9260971 9169646
Machine Model: ZX200-3 ZAX240-3 ZX200-5G
Heat Treatment: Q+T
Advantage: Low Noise, Low Vibration, High Precesion
Warranty: 6 Months
Shipping Methods: DHL / TNT / UPS / SEA / AIR Shipping
Keywords: Replacement Slewing Bearing,Slewing Gear Ring,Excavator Slewing Ring,Swing Ring Circle,Excavator Reduction Parts
More Part Number 1: 227-6089 227-6090 353-0489 227-6089 353-0680 353-0490 227-6052 136-2969 200-3645 227-6094 136-2970 169-5536/169-5537 227-6037
More Part Number 2: 227-6052 353-0490 333-3009 367-8361 199-4491 227-6099 227-6098 227-6099 227-6099 227-6082 7Y1563 7Y1563 8K4127
Highlight:

9260971 Excavator Swing Ring

,

ZX200-5G Excavator Swing Ring

,

ZX200-3 Excavator Swing Ring

Basic Infomation
Place of Origin: Made In China
Brand Name: Glparts
Certification: ISO9001
Model Number: ZX200-3 ZAX240-3 ZX200-5G
Payment & Shipping Terms
Packaging Details: Wooden Case
Delivery Time: 7 Days
Payment Terms: T/T,Western Union,MoneyGram
Supply Ability: 2000pieces/month
Product Description

9260971 9169646 Slewing Bearing for ZX200-3 ZAX240-3 ZX200-5G Excavator Swing Ring Circle


Product Detail



Product Name Swing Bearing,Slewing Bearing Place of Origin Guangzhou,China
Model ZX200-3 ZAX240-3 ZX200-5G Application for Hitachi ZX200-3 ZAX240-3 Excavator
Part Number 9260971 9169646 Heat Treatment  Q+T
Warranty 6 Months Stock Some Model in Stock


Company Profile



With over 16 years of expertise in the excavator parts industry, GLPARTS specializes in manufacturing hydraulic cylinders (arm, boom, bucket) and supplying a full range of excavator components, including hydraulic pumps, control valves, gear pumps, motors, diesel engines, slewing bearing, solenoid valves, oil seals, and hydraulic cylinder tools.

We serve clients in more than 100 countries, such as the United States, Australia, Indonesia, and Brazil, earning a strong reputation for reliability and consistent quality. From raw material selection to final testing, we enforce strict quality control to ensure outstanding durability and performance.

Backed by a skilled team and fast delivery capabilities, GLPARTS is committed to providing not just parts, but complete solutions — built to perform, made to last.9260971 9169646 Slewing Bearing for ZX200-3 ZAX240-3 ZX200-5G Excavator Swing Ring Circle 0

Slewing Bearing Installation Guide



1. Positioning
Mark the mounting position accurately on the base or structure according to equipment requirements. Ensure the alignment of bolt holes and orientation corresponds with the machine layout.

2. Hoisting
Use appropriate lifting equipment to raise the bearing steadily above the installation area. Lower it slowly, maintaining horizontal and vertical alignment, and avoid collisions.

3. Initial Mounting
Align the mounting holes and loosely insert the bolts. Do not fully tighten to allow fine adjustment during alignment.

4. Alignment Adjustments

Leveling: Use a level gauge to measure the flatness. Shim as needed to meet flatness tolerances.

Perpendicularity: For vertical installations, check verticality using a plumb line or measuring tool.

Clearance Check: Use a feeler gauge to measure the gap between the bearing and adjacent parts. Adjust to ensure uniform clearance per design specs.

5. Final Fixing
Once aligned, tighten bolts in a cross pattern using a torque wrench to the specified torque values. Ensure even load distribution.

6. Post-Installation Checks

Visual Check: Confirm all bolts are securely fastened and there are no surface damages or looseness.

Rotation Test: Manually or via drive system, rotate the bearing slowly to ensure smooth motion without noise or jamming.

Lubrication Check: Verify oil level and grease quality; ensure the lubrication system functions properly.

Seal Inspection: Ensure seals are properly installed and effective, with no leaks. Replace if necessary to prevent contamination.


More Bearing We Can Provide



Part Number Description Model
9196732 Excavator Zx225us Swing Circle Slewing Ring Zx225us
9260971 Excavator Zx330 Slewing Bearing Slewing Ring Zx330
9154037 Excavator Ex270 - 5 Turntable Ball Bearing Slewing Ring Ex270 - 5
9154037, 9159646 Excavator Zx230 Internal Gear Slewing Rings Zx230
9196732, 9245728 Excavator Zx240 Slewing Bearing Slewing Ring Bearing Zx240
9112188 Excavator Ex300 - 3 Replacement Ball Bearing Slewing Ring Ex300 - 3
9245698 Excavator Zx330LC - 5g Slew Ring Slewing Bearing Zx330LC - 5g
9245698 Excavator Zx350 - 3 Excavator Slewing Bearing Slewing Ring Zx350 - 3
9166468, 9169894 Excavator Zx370 Slewing Bearing Slewing Ring Zx370
9099074 Excavator Kh180 - 3 Internal Gear Slewing Bearing Kh180 - 3
9129521 Excavator Ex400 - 5 Ball Bearing Slewing Ring Bearing Ex400 - 5
9129521 Hitachi Excavator Zx450 Internal Gear Slewing Rings Zx450
